Product Code: 007.1R
A DIY, self-assembly kit, with all materials supplied in standard lengths which need to be cut down to the required sizes during assembly.
When ordering you will require 3 measurements, as per the diagram, to enable you to choose a kit size
W1 - width of track.
This is the "end to end" track measurement. This can be the full width of the door frame or less if skirting overlaps the frame.
H - total heght of system
This is the measurement from the bottom of the bottom track to the top of the top track.
W2 - width of the screen required
This will be the width of the screen which will overlap the door frame on one side and the middle bar on the other,
As long as W1, H & W2 are within the measurements specified for a kit, that kit will be the correct kit for you e.g. if W1 = 1900mm, H = 2020 and W2 = 950mm then the smaller kit (1980mm x 2040mm x 990mm) is the kit you require.
We offer two types of mesh with this screen. Your choice will depend on which insects you wish to keep out.
BetterVue insect mesh - 18 x 18 holes per square inch
Examples of insects this mesh will keep out:
BetterVue insect mesh is designed and manufactured to ensure maximum visibility (through the screen) ensuring as much light passes into the room as possible.
We recommend this mesh for all areas of the UK except in parts of Scotland where Midges are present and other parts of the UK where Corn Flies and Thunder Bugs/Thrips are present.
Midge mesh - 30 x 20 holes per square inch
This mesh will keep out:
Midge mesh has a tighter weave than BetterVue insect mesh to ensure Midges, Corn Flies and Thunder Bugs/Thrips cannot penetrate, however the visibility and airflow is reduced slightly.
We recommend this mesh in parts of Scotland where Midges are present and other parts of the UK where Corn Flies and Thunder Bugs/Thrips are present.
Please note - genuine Midge mesh is 30 x 20 - anything less e.g. 20 x 20 or 18 x 16 will not keep midges out.
A DIY kit to make a single sliding fly screen, designed to be fitted flush against the door frame surfaces.
Ideal for use for use with patio doors, or where there is a fixed panel next to the opening door. Offering an effective solution to keep out flies, wasps, mosquitos, midges, moths and other unwanted insects.
Supplied as a DIY kit, which comes with a full set of instructions and all parts needed to make and fit the finished screen.
Choice of 2 kit sizes.
Genuine 30 x 20 midge mesh option also available.
For larger doors, please call us.
